Y81Q-135B YE81Q-135D YE81Q-200
Scrap Metal Baler

Scrap Metal Baler

This product has been discontinued and removed from our shelves.

Parameters

Power System (Motor)
Type Y200L2-6
Rated Power 22 kW
Rated Speed 970 rpm
Power Specification 3PH, 50 / 60Hz
Hydraulic System (Pump)
Type 160YCY14-1B
Rated Displacement 160 ml/r
Max Operating Pressure 31.5 MPa
Operation System (Optional)
Option 1: Manual Valve Operation
Option 2: PLC Operation
System Parameters
Lid Cyl. Force 50 Ton
Main Pressure Cyl. Force 135 Ton
Front Door Cyl. Force 2×24 Ton
Hydraulic System Pressure 25 MPa
Idle Cycle Time Approx. 70 Sec.
Standard Configuration
A3 Steel Liners, Surface Heat Treatment.
Optional Configuration
Cutting Blades and Teeth (2 sides)
Cooler / Heater
Diesel / Diesel Generator for Power.
General Description
Main Machine Size (L×W×H) 4100×1300×2000 mm
Press Box Size (L×W×H) 1300×600×600 mm
Bale Size (W×H) 600×240 mm
Bale Weight (Steel) 50-75 kg
Production Rate (Steel) 1.5-2.0 tons/hr
Shipping Weight Approx. 6.6 tons
Loading (Standard Containers)
Hydraulic Oil Brand Oil Tank Volume: 1200 ltr
ISO VG China U.S. Britain France
GB11118.1 CALTEX CO. MOBIL SHELL ELF CO.
HM 46 46 # Rando HD46 D.T.E46 Tellus 46 Elfolna 46
HM 68 68 # Rando HD68 D.T.E68 Tellus 68 Elfolna 68

The above information is subject to change without prior notice.

Huahong is a scrap metal baler manufacturer, based in China. We offer scrap metal baler, full automatic baler, scrap steel shear, waste paper baler and plastic baler to customers worldwide. We provide high quality products at a competitive price. Our company is based in Jiangsu province where there is a complete production chain. Lower manufacturing cost saves your purchasing cost. For more details, please click on the concrete product page.
